Scheme of works for using a scanner, digital camera and Photoshop Course spring 2004



Lesson 7


Digital camera section

Managing pictures ( Making copies, creating subfolders)

Be aware that some cameras allow you to create folders on your memory card, you may also be able to make copies of pictures which are set at a different resolution to the original. This is useful if you are running out of storage space and need to take more pictures. Firstly delete unwanted pictures, secondly lower the resolution of any pictures you may take from then on during that session. - Check out other ways to lower the amount of memory a picture takes up, settings such as quality and compression will also have an effect - . If you're still lacking storage space you might be able to use the copy function. If you do so, save the new one at a much lower resolution. For instance you may have a picture that doesn't need to be saved at high resolution - approx. 2400 x 1600 - so you make a copy which is 600 x 400 and then delete the original. By doing this you'll have gained enough space to shoot 15 pictures at 600 x 400. A useful feature in emergency situations.

Putting a zoom feature to use

Firstly if your camera has a digital zoom avoid using that feature. If it has both an optical and a digital one then try to only use the optical one. A digital zoom is just an enlargement of a part of the ccd chip that senses the image in your camera, you may as well crop your image and enlarge it in photoshop than use a digital zoom.

If you have an optical zoom however it can be put to many uses. The first one is to zoom in on things that are distant, but it can also be put to less obvious uses. Firstly when wanting to take a close up of someone's face you'll find that if you hold a camera too close it will distort their features and will probably be hard to focus. Holding things close to your eyes makes the things look bigger, the closer they get the larger they look, we all know this - hopefully -. From your eye to about a foot away you will see the most dramatic effect. Therefore if you have a person's nose 7 inches away from a camera lens and their eye is 8.5 inches away the nose will look disproportionately bigger than it should in relation to the eye. The face may even look like a caricature. If you want to overcome this then step away from your subject and frame your picture around their face using your zoom, it'll be far less likely to distort their features.

There is an area between around 3 foot and 1 foot from your camera that many cameras find hard to focus on. If this happens move away from your subject and use your zoom to get the close up you require.

When zooming less light comes in to the camera. The speed of a lens denotes how much light it can let in, a faster lens will be able to zoom in on subjects in darker situations than a slower lens. Remember if you're not able to get enough light to take a picture try zooming out, you might find more light comes through the lens.

If you take a picture using a flash you might find that being close up to a subject washes out (over exposes) the image, if that's likely to happen take a picture from further away using the zoom, that way the luminosity caused by the flash won't be so intense.


Flash guns

For those of you who wish to get into photography in some depth:

Does your camera have an interface for an add on flash device? This will either be a plug in socket for a "flash cable" or a slide on socket known as a "hot shoe". If you can add a flash gun you'll find a bounce head one can allow flash photos to be taken with a far more subtle effect.


Photoshop section

Colour range select tool

This technique is particularly useful when you have an area that's got lots of things in front of it, such as sky or a wall might have.

Sometimes you'll have an area, or multiple areas of a picture that consist of a colour range. For example a sky is often of a similar hue, so if you wanted to select the sky this feature might be useful. Go to the "select" drop down menu and choose "Color range". A window will appear. Choose the pipette with a plus sign next to it and start clicking on the area you want to select in the picture. A black and white image will show you what area will be included in the selection. If too large or small an area gets selected adjust the fuzziness slider and see if that has a positive effect. When the area you want to select is shown in the preview window to have turned white click on "ok". If you find extra selections outside of the area you want have also been selected you can tidy up the selection by using the lasso or polygon or rectangular marquee while holding down the ALT key to de-select those areas. If certain areas within the area you want to select are not selected use the selection tools while holding down the SHIFT key to get rid of them.


The "Replace Colour" function

Here's an orange house

Have a go at changing the colour of the house using the replace colour tool. (Image > Adjustments > Replace colour)
If other areas of thepicture change colour too then either select the area you want to use before using the replace colour function or lower the fuzziness setting in the replace color options box.




During lesson 7 the following topics were put forward as areas to cover over the next 5 weeks.

1 preparing images for e-mail, printing, third party printing, handouts, slide shows, and archives

2 Backing up on to CDs and DVDs

3 Dealing with red eye

4 Picture restoration

5 Adding Text

6 Improving composition

7 Putting pictures in to Word and other applications

8 Further understanding of file types

9 Practical projects

End of lesson 7

Extra for previous term's students


Dissipating Flash

Brushes - advanced

Dissipating Flash

Brushes - advanced

Text -advanced

The rotate image function

Layer masks
