Scheme of works for using a scanner, digital
camera and Photoshop Course spring 2004
Introduction and induction
what to think about when getting a digital camera
Discussing the advantages and disadvantages of using a digital
An overview of the screen
Make a new file, scribble a bit, then close Photoshop
End of lesson 1
Below is what we covered on the 15th January
Digital camera section
The basics of how a digital camera works
Common features of digital cameras.
Protecting the lens / camera / use the strap and lens cap
A resolution to understand Pixels (Picture elements) get students to
create a 10 pixel image then define it to print at A4 then do the same
with different size pictures. Demonstrate then try out.
The toolbox and its sections
The options toolbar.
Using F key
Using shift and TAB
Creating a new file - basic
Defining how big the "canvas is"
Selecting the basic drawing tools
Using the magnifying class to zoom in
Double clicking on the hand and magnifying glass icons to
change the view
Undo and history
Saving the image at different points by using "Save
Understanding different file types
End of lesson 2
Digital camera section
Working without the flash
Loading pictures on to a PC using a card reader
The different palette windows > moving them around and
switching them in to groups.
Defining a custom workspace
Adjusting contrast using contrast function and levels function
Adjusting hue / saturation and lightness.
And now with a hue adjustment
The rotate image function
from this session
End of lesson 3
Selecting a piece of text from a
1 ...Click once
anywhere on this line , or anywhere just above the beginning of the
text you want to select
2 ...Then scroll to the end of this lesson.
down the shift button then click on the line that's red and says
here while holding down the shift key".
Managing pictures ( Deleting, protecting, making copies,
Formatting Vs deletion
Basics of taking photos ..... This includes:
What to think about when taking a picture
Looking at the edge of the frame
Keeping both eyes open
Taking portraits. Close up?
Landscapes and detail.
Recap last week
Opening files the normal way and then using the file browser
(basic) and then using the drag and drop technique
The free transform function
The crop function
pictures taken in this weeks lesson
Selection menu and basic techniques
End of lesson 4
"click here while holding down
the shift key"
Digital Camera section
An exercise in depth of field in relation to portrait photography.
Using the lock down technique take a picture of someone in the class,
make sure the focus is on their face, and if possible open up the aperture
as wide as possible, then take some shots.
An explanation of "depth of field"
See the following links for further reading
of field simplified or this
2 Medium Depth
of field explanation
3 Technical http://www.normankoren.com/Tutorials/MTF6.html
An example of depth of field in action
Composition 2 (divisions of an area - The
golden mean rule, left to right rule, the directions subjects look
in.) further reading link
The direction in which a subject looks influences how the composition
works, in this example the figure on the right "bounces" the
onlookers gaze back to the figure on the left, who in turn focuses our
attention on her eyes and face.
To do anything (change, delete, filter etc... ) either a
part or all of an image one must firstly select the area
Selection techniques using the selection drop down menu
and the selection section of the toolbox.
Inverse selection, deselecting, selecting all
Adding to and cutting out selections using the shift and
Filling and stroking
The lasso, polygon lasso and the magnetic lasso
End of lesson 5
Using a digital camera section
Group pictures, a problem of resolution? If you need the details of peoples
faces your camera may not be able to capture such fine details. Always
set your resolution to as high as possible for group pictures. It might
be worth using a higher quality file format such as TIFF or RAW for important
If you use low resolution settings the individual faces may appear blocky
when you zoom in to look at them
see the other group photos taken during this lesson click here
Creating a safe haven for your photos on your hard drive. Making files
read only. Learning to save a version of a picture as soon as you bring
it out of your "Safe haven" folder.
Copy and paste
Contrast and brightness
hue and saturation
End of lesson 6
Want to blend images together? Then you'll have to wait till after half
Digital camera section
Managing pictures ( Making copies, creating
Be aware that some cameras allow you to create folders on
your memory card, you may also be able to make copies of pictures which
are set at a different resolution to the original. This is useful if you
are running out of storage space and need to take more pictures. Firstly
delete unwanted pictures, secondly lower the resolution of any pictures
you may take from then on during that session. - Check out other ways
to lower the amount of memory a picture takes up, settings such as quality
and compression will also have an effect - . If you're still lacking storage
space you might be able to use the copy function. If you do so, save the
new one at a much lower resolution. For instance you may have a picture
that doesn't need to be saved at high resolution - approx. 2400 x 1600
- so you make a copy which is 600 x 400 and then delete the original.
By doing this you'll have gained enough space to shoot 15 pictures at
600 x 400. A useful feature in emergency situations.
Putting a zoom feature to use
Firstly if your camera has a digital zoom avoid using that
feature. If it has both an optical and a digital one then try to only
use the optical one. A digital zoom is just an enlargement of a part of
the ccd chip that senses the image in your camera, you may as well crop
your image and enlarge it in photoshop than use a digital zoom.
If you have an optical zoom however it can be put to many
uses. The first one is to zoom in on things that are distant, but it can
also be put to less obvious uses. Firstly when wanting to take a close
up of someone's face you'll find that if you hold a camera too close it
will distort their features and will probably be hard to focus. Holding
things close to your eyes makes the things look bigger, the closer they
get the larger they look, we all know this - hopefully -. From your eye
to about a foot away you will see the most dramatic effect. Therefore
if you have a person's nose 7 inches away from a camera lens and their
eye is 8.5 inches away the nose will look disproportionately bigger than
it should in relation to the eye. The face may even look like a caricature.
If you want to overcome this then step away from your subject and frame
your picture around their face using your zoom, it'll be far less likely
to distort their features.
There is an area between around 3 foot and 1 foot from your
camera that many cameras find hard to focus on. If this happens move away
from your subject and use your zoom to get the close up you require.
When zooming less light comes in to the camera. The speed
of a lens denotes how much light it can let in, a faster lens will be
able to zoom in on subjects in darker situations than a slower lens. Remember
if you're not able to get enough light to take a picture try zooming out,
you might find more light comes through the lens.
If you take a picture using a flash you might find that
being close up to a subject washes out (over exposes) the image, if that's
likely to happen take a picture from further away using the zoom, that
way the luminosity caused by the flash won't be so intense.
For those of you who wish to get into photography in some
Does your camera have an interface for an add on flash device?
This will either be a plug in socket for a "flash cable" or
a slide on socket known as a "hot shoe". If you can add a flash
gun you'll find a bounce head one can allow flash photos to be taken with
a far more subtle effect.
Colour range select tool
This technique is particularly useful when you have an area
that's got lots of things in front of it, such as sky or a wall might
Sometimes you'll have an area, or multiple areas of a picture
that consist of a colour range. For example a sky is often of a similar
hue, so if you wanted to select the sky this feature might be useful.
Go to the "select" drop down menu and choose "Color range".
A window will appear. Choose the pipette with a plus sign next to it and
start clicking on the area you want to select in the picture. A black
and white image will show you what area will be included in the selection.
If too large or small an area gets selected adjust the fuzziness slider
and see if that has a positive effect. When the area you want to select
is shown in the preview window to have turned white click on "ok".
If you find extra selections outside of the area you want have also been
selected you can tidy up the selection by using the lasso or polygon or
rectangular marquee while holding down the ALT key to de-select those
areas. If certain areas within the area you want to select are not selected
use the selection tools while holding down the SHIFT key to get rid of
The "Replace Colour" function
Here's an orange house
Have a go at changing the colour of the house using the
replace colour tool. (Image > Adjustments > Replace colour)
If other areas of thepicture change colour too then either select the
area you want to use before using the replace colour function or lower
the fuzziness setting in the replace color options box.
During lesson 7 the following topics were put forward as
areas to cover over the next 5 weeks.
1 preparing images for e-mail, printing, third party printing,
handouts, slide shows, and archives
2 Backing up on to CDs and DVDs
3 Dealing with red eye
4 Picture restoration
5 Adding Text
6 Improving composition
7 Putting pictures in to Word and other applications
8 Further understanding of file types
9 Practical projects
End of lesson 7
Introduction to scanning images
Quick history of scanners
Mention hand held - including pen scanners -, drum and flat
bed - also pass through (such as fax machines) .
Mention different interfaces, different pass modes, speeds,
and extras such as slide / film negative functions, sheet feeders, expandable
"Resolution and bits". Interpolation
Uses. make a lst with the group of uses.
What is TWAIN
TWAIN is a widely-used program that lets you scan an image (using a
scanner) directly into the application (such as PhotoShop) where you
want to work with the image. Without TWAIN, you would have to close
an application that was open, open a special application to receive
the image, and then move the image to the application where you wanted
to work with it. The TWAIN driver runs between an application and the
scanner hardware. TWAIN usually comes as part of the software package
you get when you buy a scanner. It's also integrated into PhotoShop
and similar image manipulation programs.
The software was developed by a work group from major scanner manufacturers
and scanning software developers and is now an industry standard. In
several accounts, TWAIN was an acronym developed playfully from "technology
without an important name." However, the TWAIN Working Group says
that after the name chosen originally turned out to be already trademarked,
an 11th hour meeting of the group came up with TWAIN, deriving it from
the saying "Ne'er the twain shall meet," because the program
sits between the driver and the application. The name is not intended
to be an acronym.
Digital Camera section
Composition : Positioning of the horizon line - Angle And height.
Using the crop technique
Panoramic camera or special lens? No just a crop of the image below
The canvas size function in Photoshop allows you to make
more space around an image so you can insert images next to it.So for
example this technique can be used for panoramic images as you can see
The history tool - Don't forget it!!!
The Canvas Size and image size
Introduction to panorama pictures - using either the crop
feature or putting two or more pictures together
A quick introduction to Filters
Here's an example of the "motion blur" filter
Here's a picture after the Watercolour filter has been applied
End of lesson 8
Exposure compensation (Exposure Values) - Bracketing - 5
The importance of empty spaces and blocks of colour
/ texture 5
You may need to make several attempts at the following
before you get a shot you're happy with.
1 Take a standard head and shoulders shot of someone in
the class. Pay attention to the background. 5
2 Take an "arty" portrait of someone in the class.
Once you have got the shots you like we shall download them
to my laptop and review them. 15
here are sme of the photos taken
during this session
(So far 1:15 hours)
Our first glance at layers 10
Introduction to the text tool - notice text appears on it's own layer
at first 10
The clone tool 10
Introduction to "burning" files - pictures- on
to a CD 15
End of lesson 9
Digital Camera section
Video functions - resolution - time span / memory - making a vcd using
Nero - 20
Video taken during class
(try right clicking on this link and using the "save target as"
Do you just want a series of postcards or can you make pictures of scenes
more interesting by either adding subjects or making more dramatic images?
Colour modes - this links back to scanners 5
Why don't the colours print out as they do on the screen
- negative and positive colour mixing - RGB Vs CMYK, optimizing one's
monitor for printing - Have I ever bothered? No 5
Printing optimisation for printing 5
optimisation for multimedia display, e-mail and the Internet.5
Transform functions 10
Blur tool 10
The Unsharpen filter Want
to know more then click on this link10
Scanning an image
Installing a scanner 5
The TWAIN interface - comon features - preview - clear,
scan, resolution colour mode, selection tool.
Other features may include a flip and zoom function. 10
Start by thinking about the end output, what do you aim
to do with the image? 5
and colour modes - "line art", greyscale, and colour. 5
Scanning reflective surfaces - 2
Read about Moire
Problems with too large or too small an image. 3
7minute break (so
far 40 minutes)
The rest of this lesson will focus on out-putting images
in varied forms. e.g. Printed, email, web, video, cd, on line galleries,
on line notice boards. Yahoo
photo-album and Yahoo
free web site space and building tools
a sample slide show for you to, well, sample
The Extract filter
Recap of Selection techniques. Shift or ALT, adding to
and subtracting from selections.
Marquee, lasso, polygon, magnetic, quick masks and the magic wand.
Print screen function - can over come copy protection
Archiving - detailed and backing up to a removable storage
medium such as a CD or DVD 20
Recap of whole course including some exercises
Intermediate course ideas
Healing and patch tool
double layer blending
copying and pasting and blending options
Starting Photoshop by creating shortcuts, pinning to the
start menu, creating a keyboard start key,
Using a pen
Brushes - advanced
Layers - advanced
course page 1
To teaching Page
To home page
